Paramètres LightBurn pour la gravure

Materials LU2-2 (≤2.1W) LU2-4-SF/LF (=5W) LU2-10A (=10W) LU3-20A/B (=20W) LU3-40A (=40W) LR4-2B (=2W)
MDF Image Mode: Grayscale
Interval(mm): 0.07
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 70
 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 10000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.07
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 40		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 55		 ×
Plywood Image Mode: Grayscale
Interval(mm): 0.07
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 70		 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 10000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.1
Speed(mm/m): 15000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 80		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 80		 ×
Pine Image Mode: Grayscale
Interval(mm): 0.07
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 70		 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 10000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.07
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 70		 ×
Paulownia Image Mode: Grayscale
Interval(mm): 0.07
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 70		 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 10000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.1
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 70		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 40		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 70		 ×
Paperboard
(Cardboard Box)		 Image Mode: Grayscale
Interval(mm): 0.06
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 9000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.1
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 70		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 35		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 60		 ×
A4 Paper
(Not White)		 Image Mode: Grayscale
Interval(mm): 0.06
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 60		 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 9000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 15		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 35		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 40		 ×

For more LightBurn engraving settings, please download LightBurn Settings PDF Document Below.

Paramètres LightBurn pour la découpe

Materials LU2-2 (≤2.1W) LU2-4-SF/LF (=5W) LU2-10A (=10W) LU3-20A/B (=20W) LU3-40A (=40W) LR2-4B (=2W)
♦ MDF
3mm 		× Image Mode: Line
Speed(mm/m): 200mm
Power Min(%): 100
Perform Multiple Passes: 4
 Image Mode: Line
Speed(mm/m): 250mm
Power Min(%): 100
Perform Multiple Passes: 2		 Image Mode: Line
Speed(mm/m): 400mm
Power Min(%): 100
Perform Multiple Passes: 2		 Image Mode: Line
Speed(mm/m): 800mm
Power Min(%): 100
Perform Multiple Passes: 2		 ×
5mm × Image Mode: Line
Speed(mm/m): 200mm
Power Min(%): 100
Perform Multiple Passes: 10		 Image Mode: Line
Speed(mm/m): 250mm
Power Min(%): 100
Perform Multiple Passes: 3		 Image Mode: Line
Speed(mm/m): 600mm
Power Min(%): 100
Perform Multiple Passes: 3		 Image Mode: Line
Speed(mm/m): 600mm
Power Min(%): 100
Perform Multiple Passes: 3		 ×
♦ Plywood
1.6mm
× Image Mode: Line
Speed(mm/m): 300mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 500mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 600mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 1600mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
2.8mm × Image Mode: Line
Speed(mm/m): 300mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 300mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 500mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 1100mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
5mm × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 300mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 350mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 700mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
8mm × × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 200mm
P
ower Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 400mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
10mm × × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 8		 Image Mode: Line
Speed(mm/m): 250mm
Power Min(%): 100
Perform Multiple Passes: 2		 Image Mode: Line
Speed(mm/m): 250mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
15mm × × × Image Mode: Line
Speed(mm/m): 200mm
Power Min(%): 100
Perform Multiple Passes: 2		 Image Mode: Line
Speed(mm/m): 200mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
♦ Pine
3mm		 × Image Mode: Line
Speed(mm/m): 150mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 300mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 500mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 700mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
5mm × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 250mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 350mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 500mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
8mm × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 3		 Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 200mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 300mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
10mm × × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 2		 Image Mode: Line
Speed(mm/m): 150mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 250mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
12mm × × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 3		 Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 180mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
15mm × × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 5		 Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 2		 Image Mode: Line
Speed(mm/m): 150mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
19mm × × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 8		 Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 3		 Image Mode: Line
Speed(mm/m): 120mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×

For more LightBurn cutting settings, please download LightBurn Settings PDF Document Below.

Commencez à créer avec Ortur !

Télécharger le PDF des paramètres LightBurnTélécharger le logiciel LightBurn
  • Veuillez noter que les résultats de gravure et de découpe peuvent varier même sur le même matériau en fonction de sa finition, de sa couleur et de son épaisseur.
  • Pour obtenir des performances optimales, ajustez soigneusement la vitesse, les réglages de puissance et la longueur focale — en veillant à ce que le point focal soit aussi petit et précis que possible. Certains matériaux tels que les plaques métalliques brillantes, les surfaces transparentes ou réfléchissantes, ainsi que certains matériaux blancs ou perméables à la lumière ne peuvent pas être gravés ou découpés directement ; dans ces cas, il est nécessaire d'utiliser un marqueur noir pour créer une surface de gravure.
  • Surveillez toujours le graveur laser pendant son fonctionnement pour prévenir les risques d'incendie, et gardez un extincteur à proximité pour la sécurité. Pour des instructions détaillées, veuillez consulter les manuels d'utilisation et tutoriels officiels d'Ortur.
